22 Inch Floor Standing Touch Screen Terminals Bank Queue Inquiry Payment Kiosk
INTRODUCTION
Touch query machine is one of the most convenient, simple, natural and practical human-computer interaction equipment, which is gradually used in all aspects of our daily life. Such as business hall, postal business hall, tax collection hall, city street (city information inquiry), office building, airport, station, bank, museum, library, exhibition, hospital, Hotel and many other occasions.
It combines computer technology, multimedia technology, audio technology, network technology, industrial plastic arts, machinery manufacturing technology, streamlined integrated design, beautiful shape. It has been widely used because of its high cost performance, customized design and strong environmental adaptability.
FEATURES
1)Elegant and fashionable super slim shape design,with anti-scratch aluminum profile brushed frame,strong and durable sheet metal back shell,
wear-resisting and anti-strike 4mm tempered glass,and firm and stable metal base.
2)Different sizes are available from 32 inch,43 inch,49 inch,50 inch,55 inch,65 inch,75 inch,86 inch,98 inch,100 inch
3)Android or windows system are optional
Android or PC solution, with optional CMS software, the function includes:
Program content by provided CMS (content management system)
*Remote update content
*Link to internet
*Live video playing
*Manage &Group the display
*Timer on/ off
*Preset time playlist
*Slide show, loop play
*Rolling words
*Split screen
*Wifi/RJ45 network application
*IR touch screen Optional
4)You are more than welcome to customize the advertising display with more additional functions
Customized Options:
1.Camera
2.Printer
3.Scanner
4.Metal keyboard
5.Card reader
6.ID card reader
7.Face recognition system
8.Motion sensor
9.Wifi / 4G network
10.Management system
11.Logo customization
12.Software development
13.Shape and look redesign
14.Customize different screen features
SPECIFICATION
| Product name | 43/49/55 inch touch screen kiosk/indoor information kiosk/shopping mall kiosk |
Screen specification | Screen specification | 55 inch(optional) |
| | Highest resolution | 3840*2160P |
| | Viewing angles | 178° horizon, 178 °vertical |
| | Brightness | 500 cd/m2 |
| | Display Scale | 16 : 9 |
| CPU specification | CPU | Intel i3 |
| | HDD | 500G |
| | Memory | 4G DDR3 (optional) |
| | Speaker | 2*10 W stereo HD8-channel (7.1) audio system |
| Other optional CPU | OS | Android 4.4 |
| | CPU | RK3188 quad core |
| | RAM | 2GB |
| | Memory | 8GB |
| | External memory | Support SD card |
| | Interface | 2×USB2.0,1×SD,2×COM,1×LAN, 1×HDMI OUT(internal),1×LVDS |
| | Networking | RJ45,WIFI |
| | Camera interface | 1×DVP,1×MIPI |
| | Signal Output Mode | video support LVDS/HDMI input,Audio support left and right sound channel |
Touch screen | Touch technology | 6/10 point infrared touch / 10 points capacitive touch |
| | Touch screen sensing | fingers, pens, any other opaque objects |
| | Resolution | 4096*4096/32767*32767 |
| | Positioning accuracy | less than 2mm |
| | Sampling rate | not less than 120Hz |
| | Refresh rate | 120FPS,response≤10ms |
| | Protective glass | 4mm ARsafety glass, hardness ≥ Mohs level 7 |
| Power | AC 110V~240V, 50/60Hz |
| Color | Black , silver and white, other colors customizable |
| Menu language | Multi-language Support |
| Warranty | 1 -3 years(12 hours after-sales service) |
